| Place of Origin: | CHINA |
| Brand Name: | MIROC |
| Certification: | ISO |
| Model Number: | 4° Taper Button Drill Bit |
| Delivery Time: | 20-30 |
|---|
| Color: | Green,blue,golden Etc | Material: | Tungsten Carbide |
|---|---|---|---|
| Taper Angle (Degree): | 4 Degree, 6 Degree,7degree,11degree,12degree | Tapered Dril Tools Types: | Button Bits,Cross Bits,Chisel Bits |
| Diameter: | 30mm 34mm 36mm 38mm 40mm 42mm | Body/ Skirt Type: | Short Skirt, Long Skirt |
| Application: | Mining, Quarrying, Tunneling | Marketing Type: | Ordinary Product |
Products Description
Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose
tapered chisel bits if the goal is to minimize hole deviation in small hole range drilling. Different taper sizes have different
characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning. Used in drifting and tunneling.
| Tapered Button Bit , 7 ° , 11° , 12° | ||||||
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 32 | 1x8 | 3x8 | 1 | 1 | 0.24 |
| 2 | 33 | 2x7 | 5x7 | 2 | 1 | 0.26 |
| 3 | 34 | 2x7 | 4x7 | 1 | 1 | 0.29 |
| 4 | 35 | 2x7 | 5x8 | 1 | 1 | 0.33 |
| 5 | 36 | 2x7 | 5x8 | 1 | 1 | 0.37 |
| 6 | 38 | 1x8 | 3x9 | 1 | 1 | 0.37 |
| 7 | 40 | 1x8 | 3x9 | 1 | 1 | 0.38 |
| 8 | 41 | 2x7 | 5x9 | 1 | 1 | 0.42 |
| 9 | 42 | 2x8 | 5x9 | 1 | 1 | 0.43 |
Features:
1. Tapered button bits connect with tapered drill rod for drilling holes
2. Stale and mature welding technology ensure good quality of bits
3. Accurate dimension of taper degree perfectly matches the rods
4. Work reliable and very cost-effective
Applications:
• Underground mining
• Dimensional Stone Industry
• Tunneling,quarrying
